FLASH 200 ELECTROSURGICAL UNIT SURTRON FLASH 200
SURTRON® FLASH 200 is a proper diathermo-coagulater to monopolar or bipolar precise surgery.
SURTRON® FLASH 200, allows to effect surgical minimally invasive treatment of resection, evaporisation and coagulation with programmable delivery time as short as thousandths of a second or for the whole time requested by a handpiece or a footswitch.
SURTRON® FLASH 200, through the selection of the functions, it lets to effect pure (CUT), coagulated-cut with different modulation duty-cycle (CUT 90%-CUT 80 %-CUT 70 %-BLEND), surface coagulation (FORCED COAG), depth coagulation in absence of carbonization (SOFT COAG) and, with special adapter, bipolar coagulation (BIPOLAR).
The digital reading of the delivered power and the overseeing through microcontroller of the operational functions, assure the absolute reliability of the conditions of job.
SURTRON® FLASH 200, by the ergonomic and safety solutions utilised, allows a highly professional surgery. It is continually monitored the connection of neutral electrode and, if a split neutral electrode is used, the impedance of the neutral electrode/patient contact is shown.
The possibility to control by the handle the output functions, as well as the output power delivery, allows to implement the surgical operation without turning away the surgeon attention from the surgical field.
SURTRON® FLASH 200, allows to effect surgical minimally invasive treatment of resection, evaporisation and coagulation with programmable delivery time as short as thousandths of a second or for the whole time requested by a handpiece or a footswitch.
SURTRON® FLASH 200, through the selection of the functions, it lets to effect pure (CUT), coagulated-cut with different modulation duty-cycle (CUT 90%-CUT 80 %-CUT 70 %-BLEND), surface coagulation (FORCED COAG), depth coagulation in absence of carbonization (SOFT COAG) and, with special adapter, bipolar coagulation (BIPOLAR).
The digital reading of the delivered power and the overseeing through microcontroller of the operational functions, assure the absolute reliability of the conditions of job.
SURTRON® FLASH 200, by the ergonomic and safety solutions utilised, allows a highly professional surgery. It is continually monitored the connection of neutral electrode and, if a split neutral electrode is used, the impedance of the neutral electrode/patient contact is shown.
The possibility to control by the handle the output functions, as well as the output power delivery, allows to implement the surgical operation without turning away the surgeon attention from the surgical field.
- Plate/patient circuit watching
- Delivery time watching
- Output power watching
- Self analysis
| SURTRON® FLASH 200 | |
| Maximum output power CUT (W) | 200 → 250Ω |
| Maximum output power CUT 90% (W) | 200 → 250Ω |
| Maximum output power CUT 80% (W) | 200 → 250Ω |
| Maximum output power CUT 70% (W) | 200 → 250Ω |
| Maximum output power BLEND (W) | 120 → 200Ω |
| Maximum output power FORCED COAG (W) | 150 → 150Ω |
| Maximum output power SOFT COAG (W) | 90 → 100Ω |
| Maximum output power BIPOLAR (W) | 100 → 100Ω |
| Working frequency | 600 kHz |
| Mains voltage (Vac) | 115 –230 |
| Mains frequency (Hz) | 50-60 |
| Electrical class (EN60601-1) | I CF |
| Neutral electrode | -F- |
| Weight Kg | 8 |
| Size HxLxD mm | 360x150x265 |
| SURTRON® FLASH 200 | |
|---|---|
| Electrosurgical unit code | 10300.40A |
| Bipolar selector | •/1 |
| Cable for neutral plate disposable/5365 | •/1 |
| Disposable split neutral electrode | •/2 |
| DisposableNeutral electrode | •/2 |
| Disposable blade electrode length 7 cm | •/3 |
| Disposable ball electrode length 7cm | •/3 |
| Disposable needle electrode length 7cm | •/3 |
| Steel neutral electrode size 120x160 mm | |
